Nu-Air NU1600 1600 CFM Heat Recovery Ventilator Review for Light-Commercial and Multi-Unit Buildings

Key Summary

The Nu-Air NU1600 is a high-capacity, sensible-only heat recovery ventilator aimed at light-commercial, multi-unit residential, and institutional projects that need balanced ventilation in cold or dry climates. It offers up to 1600 CFM of airflow, robust construction for continuous-duty operation, and straightforward HRV functionality without latent (moisture) transfer, which can be an advantage where indoor humidity needs to be controlled independently. However, it has significant physical size, cost, and installation requirements that make it better suited to larger projects, while smaller Nu-Air models may be more appropriate for individual homes or small suites.

TL;DR

• The Nu-Air NU1600 is a 1600 CFM, sensible-only heat recovery ventilator designed for larger light-commercial buildings, multi-unit residential projects, and institutional spaces that require balanced fresh air ventilation.
• As an HRV, it transfers sensible heat but not moisture between exhaust and supply air streams, which is often preferable to an ERV in cold or dry climates where excess indoor humidity or frost risk are concerns.
• It is built for continuous, high-duty operation with commercial-style blowers, durable casings, and accessible components, but requires careful duct design, adequate mechanical room space, and proper commissioning.
• External static pressure capability and duct sizing are critical: the unit can move significant air, but performance and noise depend heavily on low-restriction ductwork and well-planned distribution.
• Filtration options, noise expectations, and energy performance are generally in line with other light-commercial HRVs, but real-world results depend on filter selection, maintenance, and installation quality.
• The NU1600’s footprint, weight, and cost make it most suitable for centralized ventilation in larger projects; smaller Nu-Air units are usually a better fit for standalone houses, townhomes, or small tenant spaces.

Product Introduction

For projects that are too large for typical residential HRVs but don’t need a full custom commercial air handling unit, the Nu-Air NU1600 occupies a middle ground. It is intended as a centralized balanced ventilation solution that can serve many apartments or a sizable light-commercial floor plate from a single mechanical room. If you are considering a high-capacity HRV and comparing it with alternatives from Nu-Air and other manufacturers, this review will help you understand where the NU1600 fits, how it performs in practice, and when a smaller or different system might be the better choice.

What Is the Nu-Air NU1600 1600 CFM Heat Recovery Ventilator?

The Nu-Air NU1600 is a factory-built heat recovery ventilator rated for up to approximately 1600 cubic feet per minute (CFM) of airflow under typical operating conditions. It belongs to Nu-Air’s line of light-commercial and multi-residential HRVs, which sit between small residential boxes and fully custom commercial energy recovery ventilators and air handlers. The NU1600 provides balanced ventilation by bringing in outdoor air and exhausting stale indoor air through a heat exchanger core that recovers sensible heat from the exhaust stream to temper the incoming air.

• Balanced ventilation: outdoor air is supplied and indoor air is exhausted in roughly equal amounts to avoid pressurizing or depressurizing the building.
• Sensible heat recovery only: the heat exchanger transfers temperature (heat) but not moisture, unlike an energy recovery ventilator (ERV) that handles both sensible and latent loads.
• Centralized system: designed to connect to a duct network that can serve multiple zones, suites, or open areas from a common mechanical space.
• Continuous-duty construction: components and controls are intended for long runtimes typical of commercial and institutional ventilation schedules.

HRV vs. ERV: Why the NU1600 Uses Sensible Heat Recovery Only

A key feature of the NU1600 is that it is an HRV, not an ERV. That means it is designed to recover sensible heat from exhaust air without transferring moisture between the outgoing and incoming airstreams. Understanding the practical implications of this design choice is important, especially for projects in cold or dry climates.

How HRVs Work in Cold and Dry Climates

In cold climates, indoor air is often more humid than very cold outdoor air, even when the building feels relatively dry. When this moist indoor air passes through a heat exchanger and gives up heat to the incoming cold air, the exhaust can cool below its dew point and frost can form on the core. HRVs like the NU1600 manage this with defrost strategies (such as temporary recirculation or reduced intake), but they do not deliberately transfer moisture back into the incoming air. The result is that ventilation tends to dry the building during winter, which is helpful in homes or buildings that struggle with condensation on windows, high humidity, or moisture-related durability risks.

In dry climates, indoor humidity is often already low, and outdoor air is very dry for much of the year. Using an ERV that tries to retain moisture may partly counteract dehumidification but can also complicate humidity control strategies. A sensible-only HRV such as the NU1600 lets designers separately handle humidity with other equipment (for example, central dehumidifiers, humidifiers, or heat pump systems) without moisture transfer happening at the ventilation unit.

When an HRV Is Preferable to an ERV

• Cold climates where indoor humidity is regularly high in winter and condensation or mold risk is a concern, such as tightly built multi-unit residential buildings.
• Buildings where the design team wants predictable drying from ventilation and will manage indoor humidity with dedicated equipment, not through the ventilation unit.
• Applications with significant moisture generation (showers, cooking, laundry) where maintaining lower indoor relative humidity is a priority for building durability.
• Dry regions where preserving moisture would work against comfort goals or where indoor air quality is prioritized over maximizing energy savings from latent recovery.

In warm, humid climates where over-drying can affect comfort, or where the goal is to reduce the dehumidification load on cooling equipment, an ERV may be more appropriate. For the NU1600’s target market of cold or seasonally cold regions and mixed climates, a sensible-only HRV is often a straightforward solution that simplifies humidity management and frost control.

Airflow Capacity: What 1600 CFM Means in Real Projects

The headline specification of the NU1600 is its maximum airflow, approximately 1600 CFM under ideal or low-static-pressure conditions. In real installations, available airflow is reduced by duct friction, fittings, filters, and grilles. For designers and contractors, it is more useful to think of workable airflows under typical external static pressures and how that translates to building size and code requirements.

Matching 1600 CFM to Building Types

• Larger light-commercial spaces: small office floors, daycare centers, clinics, or community facilities that need several hundred to over a thousand CFM of continuous outdoor air.
• Multi-unit residential: centralized ventilation for a block of apartments or condominiums, supplying and exhausting modest airflow per suite from a single core unit.
• Institutional spaces: classrooms, small libraries, or meeting spaces where code ventilation rates per occupant and floor area can add up quickly.

Depending on local codes and design air change targets, a 1600 CFM HRV like the NU1600 might serve, as a rough planning example, a multi-unit building of several dozen smaller apartments at modest ventilation rates, or a smaller number of suites at higher per-unit airflow. Because airflow must be balanced with distribution layout, it is common to use one NU1600 per building section or per floor rather than attempting to serve a very large complex with a single unit.

External Static Pressure and Realistic Airflow

The NU1600 must overcome external static pressure from the duct system, filters, grilles, and external hoods. At higher static pressures, maximum airflow drops. If the ductwork is undersized or heavily restricted, the unit may not deliver its rated flow and fan energy use can increase. In design, engineers typically select an operating point on the fan curve—such as 1200–1400 CFM at a reasonable static pressure—rather than assuming 1600 CFM is available in all conditions.

• Large trunk ductwork: to keep friction losses low, main supply and exhaust trunks are commonly sized with moderate duct velocities and smooth transitions.
• Attention to fittings: elbows, tees, and branch takeoffs should be selected and installed to minimize turbulence and pressure drop.
• Balanced design: supply and exhaust paths must be similar in resistance so that the HRV maintains proper balance without excessive fan power.

In practice, if the NU1600 is installed with well-designed ductwork, it can reliably deliver a high volume of outdoor air suitable for continuous operation in larger light-commercial and multi-unit projects. If the duct system is compromised or retrofitted into tight spaces without careful design, performance, noise, and energy efficiency are likely to suffer.

Heat Recovery Performance: Efficiency and Energy Implications

The core function of the NU1600 is to reclaim heat that would otherwise be lost when exhausted air leaves the building. The unit’s sensible heat recovery efficiency describes how much of the temperature difference between indoor and outdoor air is transferred to the incoming air. For example, if outdoor air is very cold and indoor air is warm, high sensible efficiency means the incoming air is preheated significantly, reducing the load on downstream heating systems.

What to Expect from a Light-Commercial HRV Core

While exact efficiency values depend on the specific core design, test conditions, and certification method, light-commercial HRVs like the NU1600 often achieve sensible effectiveness in the range commonly seen in residential and small commercial units. Performance can vary with airflow rate, temperature difference, and frost control strategies. Defrost cycles, for instance, reduce average efficiency during very cold weather because some of the time the unit must warm the core instead of delivering full heat recovery.

• Higher heat recovery reduces heating energy use but may increase the risk of frost on the core in very cold conditions, requiring more robust defrost strategies.
• Lower airflow through the core tends to increase heat recovery effectiveness but must be balanced against ventilation requirements and fan power use.
• Filter loading and poor maintenance can decrease airflow and alter operating points, indirectly affecting both energy use and practical efficiency.

For building owners, the most important takeaway is that the NU1600 is designed to substantially reduce the heating penalty of bringing in cold outdoor air, especially compared to simple exhaust-only or supply-only systems. Over time, this can translate into noticeable energy savings and improved comfort near supply diffusers, particularly in cold or mixed climates where winter operation is significant.

Filtration Options and Indoor Air Quality

Ventilation is not just about airflow; filtration quality has a major impact on indoor air quality, equipment cleanliness, and occupant health. The NU1600, like other light-commercial HRVs, typically includes filter racks or compartments for both supply and exhaust air streams. These filters protect the core and fans from dust and debris, while supply filters can also improve delivered air quality for occupants depending on the filter rating selected.

Filter Types and Ratings

• Basic panel filters: often lower MERV ratings that mainly protect the HRV core and fans from larger particles but have limited impact on fine particulates.
• Upgraded MERV filters: higher-rated filters can capture smaller particles, including some fine dust, pollen, and other contaminants, improving indoor air quality.
• Custom filtration strategies: in some projects, designers use upstream or downstream filter banks in associated ductwork to achieve higher filtration levels while managing static pressure and filter replacement logistics.

Higher-efficiency filters create more resistance to airflow, increasing the static pressure the NU1600 must overcome. This can reduce delivered airflow or increase fan energy use if not considered in design. When specifying the unit, it is important to account for the expected filter types and replacement schedules so that the fans and ductwork are sized for the real-world pressure drop, not just ideal conditions.

Maintenance and Access

For multi-unit and institutional projects, ease of access for filter changes is a practical concern. The NU1600’s casing and panel layout are designed for maintenance access to the filters and core, but actual accessibility depends heavily on how the unit is installed. Sufficient clearance around the unit, good lighting, and clear labeling support regular maintenance, which in turn preserves airflow, efficiency, and air quality over the life of the system.

Noise Expectations: Fans, Airflow, and Occupant Comfort

A 1600 CFM HRV is a substantial piece of mechanical equipment, and noise is a reasonable concern in projects with sensitive occupants or quiet-use spaces. The NU1600 uses fans sized to move large volumes of air against commercial-style duct systems, which inevitably generates sound. How much of that sound reaches occupied spaces depends more on installation design than on the HRV itself.

Key Factors That Influence Noise

• Mechanical room location: placing the NU1600 in a well-separated mechanical space away from dwellings, classrooms, or offices reduces direct fan noise exposure.
• Duct velocities: higher airspeeds in ducts create more noise at grilles and in the ductwork; larger ducts allow lower velocities and quieter operation.
• Duct lining and silencers: acoustic lining or inline sound attenuators can reduce fan and air noise transmitted along ducts to occupied rooms.
• Isolation from structure: flexible connections, vibration isolators, and careful mounting reduce structure-borne noise and vibrations.

In a well-designed system, occupants in apartments, offices, or classrooms served by the NU1600 typically hear only gentle air movement at diffusers and minimal mechanical noise. In retrofits or cost-constrained installations where ducts are undersized or acoustic measures are limited, noise levels can be noticeably higher. For light-commercial and institutional owners, this means that investing in proper duct design and basic acoustic detailing is as important as the HRV selection itself.

Continuous, High-Duty Operation and Reliability

Light-commercial and institutional ventilation systems often run for long hours—sometimes 24/7, depending on occupancy patterns and code requirements. The NU1600 is built for continuous-duty operation with components, motors, and controls selected for these demanding schedules. That said, actual reliability and lifespan depend on proper sizing, installation quality, and routine maintenance.

Design Considerations for Continuous Operation

• Appropriate sizing: selecting the NU1600 within its optimal airflow range helps avoid operating it constantly at or near its maximum capacity, which can extend fan and motor life.
• Duty cycle matching: some facilities can use setback modes or reduced-speed operation during unoccupied hours, lowering wear and energy use.
• Accessible components: fans, filters, and cores that are reasonably easy to access and service support preventive maintenance instead of reactive emergency repairs.

In multi-unit residential and institutional settings, a centralized HRV like the NU1600 becomes a critical piece of life-safety and comfort infrastructure: if it fails, many suites or rooms lose their primary fresh air source at once. For this reason, some designers consider redundancy (such as multiple smaller units or parallel systems) or carefully plan service intervals and spare parts strategies to reduce downtime risk.

Installation Considerations: Duct Sizing, Static Pressure, and Layout

The NU1600’s performance is closely tied to how it is installed. Even the best HRV will underperform if paired with undersized ductwork, poorly placed diffusers, or high-resistance fittings. For larger light-commercial and multi-unit projects, engaging a mechanical engineer or experienced HVAC designer is strongly recommended to ensure that the system meets airflow targets with reasonable noise and energy use.

Duct Sizing and Routing

• Main trunks: supply and exhaust trunks serving the NU1600 typically require large diameters to keep velocities and pressure drops manageable at higher flows.
• Branch ducts: branches to individual suites or zones should be sized for the required local airflow while maintaining acceptable velocities and balancing capability.
• Routing and space: mechanical chases, ceilings, or bulkheads must accommodate the size of ducts needed for 1600 CFM-class equipment; space limitations may necessitate design revisions or multiple smaller units.

If duct space is constrained, designers may opt to serve fewer suites per HRV, use multiple units, or accept lower ventilation rates per suite to stay within practical duct dimensions. For institutional spaces, carefully locating diffusers and returns can improve perceived comfort and mixing, making better use of available airflow.

External Static Pressure Management

The NU1600’s fans are designed to handle the external static pressure typical of light-commercial duct systems. However, every elbow, damper, grille, and filter adds resistance. If total static pressure exceeds the HRV’s capabilities, it will not deliver design airflow without excessive noise or energy use. Good practice includes calculating or modeling duct pressure drops, selecting low-pressure-drop components, and commissioning the system to confirm that reality matches the design.

Electrical Requirements and Controls Integration

A 1600 CFM light-commercial HRV is a substantial electrical load compared with small residential units. The NU1600 requires appropriate electrical service, overcurrent protection, and disconnects consistent with local codes and manufacturer guidance. In many light-commercial and institutional facilities, the HRV is integrated into building automation or control systems to coordinate schedules, fan speeds, and defrost modes with other equipment.

Power, Wiring, and Control Strategies

• Dedicated electrical circuit: the NU1600 typically needs its own appropriately sized circuit and breaker, specified during design and installed by a qualified electrician.
• Control interface: depending on the configuration, the HRV may be controlled by local switches, time clocks, occupancy sensors, or integrated building management systems.
• Coordination with heating and cooling: in some projects, the HRV operates alongside variable refrigerant flow (VRF), boilers, or heat pumps; control logic should ensure that ventilation, heating, and cooling strategies work together rather than against each other.

For multi-unit residential buildings, designers must decide how the centralized HRV operation relates to in-suite systems. Some projects run ventilation continuously at a base rate, while others modulate ventilation based on occupancy or indoor air quality sensors. The NU1600’s suitability for these strategies depends on the specific controls package and how it is integrated into the overall system.

Space Planning and Physical Size: Fitting the NU1600 into Your Building

Compared with residential HRVs, the NU1600 is physically large and relatively heavy. It is intended to be installed in mechanical rooms, dedicated service spaces, or occasionally rooftop enclosures, not tucked into small closets. For many multi-unit and institutional projects, allocating adequate space for ventilation equipment is a design challenge that must be addressed early in planning.

Mechanical Room and Access Requirements

• Floor space and clearance: the NU1600 footprint, plus required clearances for service access and duct connections, demands a larger mechanical room than a typical single-family HRV.
• Structural support: floors or supports must carry the weight of the unit, especially if mounted above grade or suspended.
• Delivery and installation path: doorways, corridors, and stairs must accommodate the size of the unit during delivery and placement, which can be a constraint in renovations.

Insufficient space or difficult access often leads project teams to consider multiple smaller units distributed across a building rather than a single large HRV. While multiple units can increase equipment count and maintenance points, they may simplify duct routing and improve redundancy, especially in complex layouts or retrofit conditions.

Commissioning: Balancing Airflows and Verifying Performance

Commissioning is essential to ensure that the NU1600 actually delivers the design ventilation rates and heat recovery performance in real-world operation. For multi-unit residential and institutional projects, commissioning typically includes measuring supply and exhaust airflow, balancing the system, confirming controls operation (including defrost), and verifying that noise and comfort are acceptable in occupied spaces.

Key Steps in HRV Commissioning

• Airflow measurement: using flow hoods, pitot tubes, or other instruments to confirm that the NU1600 and its distribution system are delivering the specified CFM to each zone or suite.
• Balancing: adjusting dampers and controls so that supply and exhaust flows are matched and each area receives appropriate ventilation without over- or under-pressurization.
• Controls verification: checking that fans respond to schedules or commands, defrost cycles operate as intended, and alarms or safeties function correctly.
• Noise and comfort checks: confirming that sound levels and air distribution meet design expectations in typical occupied conditions.

Without proper commissioning, even a well-designed NU1600 installation can fall short of expectations. Balancing errors, miswired controls, or unrecognized restrictions in the duct system can compromise performance, energy efficiency, and occupant satisfaction. For that reason, involving experienced commissioning agents or HVAC technicians is an important part of deploying this equipment successfully.

Practical Limitations: Size, Cost, and Project Fit

Although the NU1600 can be an effective ventilation solution for large light-commercial and multi-unit projects, it is not the right fit for every building. Its physical size, purchase cost, and installation requirements mean that it is best suited to projects with enough scale to justify a centralized 1600 CFM HRV. For smaller buildings or those with fragmented floor plans, smaller Nu-Air models or multiple distributed units may provide better flexibility and lower installed cost.

When Smaller Nu-Air Models Are More Appropriate

• Individual single-family homes or duplexes where total ventilation needs are well below 1600 CFM and mechanical room space is limited.
• Townhome blocks or small multi-unit buildings where each unit has its own mechanical room, making distributed residential-sized HRVs simpler and more flexible.
• Small tenant improvements in commercial buildings where shared base-building ventilation exists and only modest supplemental ventilation is required.

Centralized systems like the NU1600 excel when there is a clear, pooled ventilation demand and a mechanical infrastructure designed to support them. If a project’s ventilation requirements are modest, highly variable, or spread over disconnected spaces, multiple smaller HRVs or ERVs—including lighter-duty Nu-Air models—may be more practical and cost-effective.

How the Nu-Air NU1600 Compares in the Market

In the broader light-commercial ventilation market, the NU1600 competes with other manufacturers’ centralized HRVs and ERVs in the roughly 1200–2000 CFM range. Many competing units offer both HRV and ERV core options, pressure ranges suitable for commercial ductwork, and similar control strategies. The NU1600 distinguishes itself mainly by its focus on sensible-only heat recovery for cold and dry climates, its positioning for multi-unit residential and institutional projects, and its integration options within Nu-Air’s wider lineup of smaller and larger systems.

• In cold or dry climates where separate humidity control is desired, the NU1600’s HRV-only approach is often a strength rather than a drawback.
• In warm, humid climates or where maximizing latent energy recovery is a priority, competing ERV options from various manufacturers may offer advantages.
• For projects that prioritize redundancy or phased expansion, using multiple smaller units—whether Nu-Air or other brands—may provide more flexibility than a single large HRV.

From a building owner’s perspective, the choice among these options often comes down to climate, humidity strategy, building layout, available mechanical space, and the preference and experience of the design and construction team. The NU1600 fits best where sensible-only heat recovery, centralized distribution, and continuous-duty operation align with project goals.

Is the Nu-Air NU1600 Right for Your Project?

Choosing a 1600 CFM light-commercial HRV like the Nu-Air NU1600 is a significant design and budget decision. While the unit can provide robust, balanced ventilation and efficient sensible heat recovery for larger light-commercial, multi-unit residential, and institutional spaces, it is not a universal solution. Evaluating whether it is appropriate for your project means considering building size, climate, humidity strategy, layout complexity, mechanical room space, and long-term maintenance capacity.

• If you are in a cold or dry climate and want centralized, sensible-only heat recovery for a larger building or multi-unit project, the NU1600 is a relevant option to consider.
• If your project is small, has limited mechanical space, or requires individual control per dwelling, smaller Nu-Air units or distributed systems may be a better fit.
• If humidity control and latent recovery are key priorities in a warm or humid climate, an ERV-based solution from Nu-Air or another manufacturer may be more appropriate.

Ultimately, the NU1600 is one component in a broader ventilation and HVAC strategy. Working with a qualified mechanical engineer, HVAC contractor, or building performance consultant can help ensure that whichever system you choose delivers the right combination of air quality, energy efficiency, reliability, and occupant comfort for your specific building and climate.

Sources

• Nu-Air Ventilation Systems — Product literature and technical data for Nu-Air light-commercial HRV models https://nu-airventilation.com
• ASHRAE — Ventilation for Acceptable Indoor Air Quality (Standard 62.1 and 62.2) https://www.ashrae.org
• Natural Resources Canada — Heat recovery ventilator and energy recovery ventilator fundamentals for Canadian climates https://natural-resources.canada.ca
• U.S. Department of Energy — Energy-efficient ventilation and heat recovery guidance for residential and commercial buildings https://www.energy.gov
• Building Science Corporation — Guidance on HRV and ERV selection in cold and mixed climates https://buildingscience.com
