It's bigger than a shed but smaller than a house

Warner says of the Schallichs' ADU. "It's a nicely designed, simplified structure, so we can concentrate on just what does go into it."

Sebastopol ADU Bedroom Alchemy Architects
Sebastopol ADU Bedroom. Photo Credit: Alchemy Architects

The lightHouse is available in five sizes (small, medium, large, extra-large, and 2X), ranging from 310 to 600 square feet. It has a dozen floor plans, from a one-room studio to a one-bedroom unit above a two-car garage.

The lightHouse ADU has three exterior plans that respond to the site: an end porch, a side porch--or an entry on top of a garage. "We figure out which solution works on each client's lot and provide variations with different entrances and views," Warner says.

The entrance to the Sebastopol lightHouse is one end. "We needed to temper the sun coming in from the west, and there wasn't a view to the south, so we put the access on the east side," Warner explains. The property also has a slight slope, so Warner lowered the ADU down into the grade.

Sustainable in Sebastopol

The ADU's small footprint and factory construction (key to decreasing construction waste) aren't the lightHouse's only sustainable aspects.

The Sebastopol lightHouse has a high-performance structure or envelope that's thermally broken with a high-quality air and weather barrier. Warner says the ADU very nearly qualifies as "a passive house with a lot of additional sustainable aspects, even though we're not certifying them as passive houses."

Plant Prefab built the Sebastopol lightHouse with 2x4s, R-50 12-inch neo-core SIPs (structural insulated panels), and a plywood wall interior. The passive-house windows are triple pane, as are the insulated sliding doors. Per California code, the ADU's roof insulation and white roofing were also part of the construction.

The ADU is clad in cedar slats placed in random channels over a liquid Sip-Seal liquid membrane. The vapor-permeable, flexible weather barrier is often used for high-performance building envelopes. "We used the membrane because it simplifies window installation and detailing for keeping the house dry," Warner says, "and does a great job of keeping water out." The membrane is fire rated, as Sebastopol is in fire country.

LEDs for lighting, low-flow plumbing, no-VOC paint, ENERGY STAR appliances, and energy-efficient windows add to the package. A low-temperature Fujitsu mini-split provides both electrical heat and cooling.

Alchemy Sebastopol Kitchen Alchemy Architects
Sebastopol ADU Kitchen. Photo Credit: Alchemy Architects

The lightHouse has a kitchen with a full-size refrigerator and storage areas, separate from the sleeping area. It also includes another signature element: A built-in 30-inch-wide oak bench with removable backs to transform the structure into a bed (cushions and bedding can be kept in storage underneath).

Sebastopol ADU Bathroom Alchemy Architects
Sebastopol ADU Bathroom. Photo Credit: Alchemy Architects

In every lightHouse, the bathroom is located in the same place, regardless of the plan. It's part of a bathroom/storage core that contains all of the utilities, a washer/dryer, and a full sprinkler system. The tiled bath has a zero-threshold shower, frameless glass panels, and a touchless faucet on an enameled Dornbracht Alape sink.

"We consider the lightHouse a whole, complete, well-integrated package, in which the components work well together," Warner says.

"A Ton of Character"

The product of decades of research and design thinking, the lightHouse demonstrates Alchemy's diligence in creating small projects. "Sustainable housing with a small footprint is the right thing to do," Warner says. "Even these small projects inform our other efforts. We also love our adventurous clients, who allow us to guide them toward innovative solutions in customizing prefab to meet their needs."
